Location：Home > Products > ICET® Flooring Materials
PET core composite flooring
|
|
PET composite board (12mm) |
Bamboo plywood (15mm) |
PVC foam board (18mm) |
Testing standards |
|
|
Foam density |
100 |
|
600 |
|
|
|
KG/sqm |
5.9 | 11 | 10.5 |
|
|
|
Physical performance |
Weather resistance |
Excellent |
Good |
Poor |
|
|
Waterproof performance |
Excellent |
Poor |
Good |
|
|
|
Thermal insulation performance |
Good |
Good |
Poor |
|
|
|
Electromagnetic shielding |
Yes |
No |
No |
|
|
|
Mechanical properties |
Elastic modulus (MPa) |
9160 |
>6000 |
>3000 |
GB/T 17657-2013 |
|
Plane shear strength (Mpa) |
1.51 | —— | —— |
GB/T 1455-2005 |
|
|
Flat elastic modulus (Mpa) |
116 | 40.29 | 90 |
GB/T 1453-2005 |
|
|
Static bending strength Mpa (transverse) |
44.6 | 15.2 | 28 |
GB/T 17657-2013 |
|
|
Surface bonding strength - Method 1 (Mpa) |
0.88 | —— | —— |
GB/T 17657-2013 |
|
|
Combustion Performance of PET Material |
Damage length(cm) |
22 | —— | —— |
DIN 54837 |
|
Continued combustion(s) |
0 | —— | —— |
DIN 54837 |
|
|
Material combustion characteristics |
S3/SR2/ST2 | —— | —— |
DIN 5510-2:2009 DIN 54837:2007 |
|
|
Smoke toxicity |
Qualified |
—— | —— |
DIN 5510-2:2009
DIN EN ISO 5659-2:2007 |
|
Specification: 1220 * 2440, thickness and density can be customised
